100kw 50kw 220v-430v Low Speed Gearless Permanent Magnet Generator AC Alternators

Short Description:

1. High Efficient power generation NdFeb material; High-Grade pure copper wire winding; High-Efficiency and Stable power generation;

2. No gear, direct drive, low speed rare earth permanent magnet generator, easy to operate and maintain;

3. Special stator and rotor design, low starting resistance moment, good heat dissipation.

Inquiry

Specification

Model	FY-50KW	FY-50KW	FY-100KW	FY-100KW
Rated power	50kw	50kw	100kw	100kw
Max power	55kw	59kw	120kw	130kw
Rated speed	100rpm	70rpm	100rpm	70rpm
Rated voltage	220v/380V/430V	220v/380V/430V	220v/380V/430V	220v/380V/430V
Start Torque	167 Nm	171 Nm	279 Nm	298Nm
Rate Torque	1569Nm	1996Nm	2068Nm	3459Nm
Output Current	AC
Efficiency	＞75%
Service Life	More than 20 years
Insulation Class	F
Bearing	HRB or for you order
Generator	3 phase Permenent Magnet Synchronous Generator
Shaft Material	Stainless Steel
Shell Material	Aluminium Alloy
Permanent Magnet Material	Rare Earth NdFeB

Packing details

1) 1 PC Generator

2) 1 Set Installation screws

Other styles available:

A: Direct Shaft/Taper Shaft

B: 220V/380v/430V

C: Without Base/With Base
