factory direct sale vertical wind turbine 3kw 5kw 10kw 20kw 30kw power plant on grid off grid use

Short Description:

1, Security. Using vertical blades and triangular double-fulcrum, the problems of blade lose/broken or leaf flying-out have been well solved.

2, No noise. Coreless generator and horizontal rotation with aircraft wing design reduce the noise to an unperceivable level in natural environment.

3, Wind resistance. Horizontal rotation and triangular double fulcrum design make it only bear a small wind pressure even in strong wind.

4, Rotation radius. smaller rotation radius than other types of wind turbines, space is saved while efficiency improved.

5, Power generation curve. The power generation increasing gently , it could produce 10% to 30% more power than other types of wind turbines.

6, Brake device. The blade itself has speed protection, and can configure manual mechanical and electronic brake meantime.

Min.Order Quantity: 100 Piece/Pieces

Supply Ability: 10000 Piece/Pieces per Month

Inquiry

Features

1, Security. Using vertical blades and triangular double-fulcrum, the problems of blade lose/broken or leaf flying-out have been well solved.
2, No noise. Coreless generator and horizontal rotation with aircraft wing design reduce the noise to an unperceivable level in natural environment.
3, Wind resistance. Horizontal rotation and triangular double fulcrum design make it only bear a small wind pressure even in strong wind.
4, Rotation radius. smaller rotation radius than other types of wind turbines, space is saved while efficiency improved.
5, Power generation curve. The power generation increasing gently , it could produce 10% to 30% more power than other types of wind turbines.
6, Brake device. The blade itself has speed protection, and can configure manual mechanical and electronic brake meantime

The parts list

	Description	Quantity	REF
1	Blade	3 or 4pcs optional
2	Central shaft	1pc	Centre shaft TOP×1
3	Brackets	6 or 8pcs optional	3 pcs blades match 6pcs supports
4	Generator	1 set
5	Setscrew	M10*856pcs	Fasten the blade and Brackets
6		36pcs	washers
7		6pcs	Fasten the support and Generator

Specifications

Model	FH-4000	FH-5000	FH-10kw	FH-20kw	FH-30kw
Rated power	4000w	5000w	10kw	20kw	30kw
Maximum power	4500w	5500w	12kw	22kw	32kw
Rated voltage	48v-380v	48v-380v	220v-380v	300v-600v	300v-600v
Start-up wind speed	3m/s	3m/s	3m/s	3m/s	3m/s
Rated wind speed	10m/s	10m/s	10m/s	10m/s	10m/s
Rated RPM	300	350	200	160	130
Net weight	160kg	220kg	320kg	680kg	1280kg
Wheel diameter	2m	3m	5m	5m	8m
Blades height	2.8	3.6m	6m	7m	10m
Number of blades	4	3	3	3	5
Blades material	Aluminium alloy
Survival wind speed	45m/s
Generator type	3 phase permanent magnet AC synchronous generator
yaw mode	Electromagnet
Working temperature	-40°C-80°C
