Features
1.Low start up speed, 6 blades ,high wind energy utilization
2.Easy installation, tube or flange connection optional
3.Blades using new art of precision injection molding,matched with optimized aerodynamic shape and structure,which enhance the wind energy utilization and annual output.
4.Body of casting aluminum alloy, with 2 bearings swivel , making it survive stronger wind and run more safely
5.Patented permanent magnet ac generator with special stator,effectively reduce torque,well match the wind wheel and generator, and ensure the performance of whole system.
6.Controller,inverter can be matched accroding to customersâ specific needs
Specifications
| Model | FZ-400 | FZ-500 | FZ-600 |
| Rated Power(w) | 400w | 500w | 600w |
| Max Power(w) | 460w | 560w | 660w |
| Rated Voltage(v) | 12/24V | 12/24V | 12/24V |
| Wind wheel diameter(m) | 1.2 | 1.2 | 1.2 |
| Rated wind speed(m/s) | 13m/s | 13m/s | 13m/s |
| Start-up wind speed | 2.0m/s | 2.0m/s | 2.0m/s |
| Survival wind speed | 40m/s | 40m/s | 40m/s |
| Blade number | 3/5 | 3/5 | 3/5 |
| Service Life | More Than 20 years | ||
| Bearing | HRB or for your order | ||
| Shell material | Nylon | ||
| Blades Material | Nylon fibier | ||
| Permanent Magnet Material | Rare Earth NdFeB | ||
| Control system | Electromagnet | ||
| Lubrication | Lubrication Grease | ||
| Working temperature | -40 to 80 | ||
