Features
1.Low start up speed, 6 blades ,high wind energy utilization
2.Easy installation, tube or flange connection optional
3.Blades using new art of precision injection molding,matched with optimized aerodynamic shape and structure,which enhance the wind energy utilization and annual output.
4.Body of casting aluminum alloy, with 2 bearings swivel , making it survive stronger wind and run more safely
5.Patented permanent magnet ac generator with special stator,effectively reduce torque,well match the wind wheel and generator, and ensure the performance of whole system.
6.Controller,inverter can be matched accroding to customersâ specific needs
Specifications
| Model | S3-600 | S3-800 |
| Rated Power(w) | 600w | 800w |
| Max Power(w) | 620w | 820w |
| Rated Voltage(v) | 12/24V | 12/24V/48v |
| Blades length(mm) | 530/580 | 530/580 |
| Top net weight(kg) | 6 | 6.2 |
| Wind wheel diameter(m) | 1.1 | 1.1 |
| Rated wind speed(m/s) | 12m/s | 13m/s |
| Start-up wind speed | 1.3m/s | |
| Survival wind speed | 40m/s | |
| generator | 3 phase permanent magnet synchronous generator | |
| Service Life | More Than 20 years | |
| Bearing | HRB or for your order | |
| Blades material | nylon | |
| Shell Material | nylon | |
| Permanent Magnet Material | Rare Earth NdFeB | |
| Control system | Electromagnet | |
| Lubrication | Lubrication Grease | |
| Working temperature | -40 to 80 | |
Why Choose US
1. Competitive Price
--We are the factory/manufacturer so we can control production costs and then sell at the lowest price.
2. Controllable quality
--All products will be produced in our factory so we can show you every detail of the production and let you check the quality of the order.
3. Multiple payment methods
-- We accept online UPI and bank transfer
4. Various forms of cooperation
--We are not only offer you our products, if it is needed, we could be your partner and design product according to your requirement. Our factory is your factory!
5. Perfect after-sales service
--As a manufacturer of wind turbine and generator products for over 4 years,we are very experiences to dealing all kinds of problems. So whatever happens,we will solve it at the first time.
