Features
1.Low start up speed, 6 blades ,high wind energy utilization
2.Easy installation, tube or flange connection optional
3.Blades using new art of precision injection molding,matched with optimized aerodynamic shape and structure,which enhance the wind energy utilization and annual output.
4.Body of casting aluminum alloy, with 2 bearings swivel , making it survive stronger wind and run more safely
5.Patented permanent magnet ac generator with special stator,effectively reduce torque,well match the wind wheel and generator, and ensure the performance of whole system.
6.Controller,inverter can be matched accroding to customers’ specific needs
Package list:
1.wind turbine 1 set(hub,tail,3/5 blades,generator,hood,bolts and nuts).
2.wind controller 1 piece.
3. installation tool 1 set.
4.flange 1 piece.
Specifications
| Model | SUN-400 | SUN-800 |
| Rated Power(w) | 400w | 800w |
| Max Power(w) | 420w | 850w |
| Rated Voltage(v) | 12/24V | 12/24V |
| Blades length(mm) | 580 | 580 |
| Top net weight(kg) | 8.5 | 9.5 |
| Wind wheel diameter(m) | 1.1 | 1.1 |
| Rated wind speed(m/s) | 12m/s | 13m/s |
| Start-up wind speed | 1.3m/s | |
| Survival wind speed | 40m/s | |
| generator | 3 phase permanent magnet synchronous generator | |
| Service Life | More Than 20 years | |
| Bearing | HRB or for your order | |
| Blades material | nylon | |
| Shell Material | Alluminum alloy | |
| Permanent Magnet Material | Rare Earth NdFeB | |
| Control system | Electromagnet | |
| Lubrication | Lubrication Grease | |
| Working temperature | -40 to 80 | |
