Features
1, 1.start up wind speed<1.3m/s
2.3 outer blades
3.20years use life and 1 year for warranty
4.small ,light ,stable and safely
5.Certified with:CE, RoHS and ISO 9001 2000
6.High efficiency, could be hybrid system with solar panels.
7. Applications: Marine, Boat,Streetlights, Home, Openning Plaza lighting..
Specifications
| item | Q1-300 | Q-600 | Q-1000 | Q-3000 | Q-5000 |
| Started wind speed (m/s) | 1.3m/s | 1.3m/s | 1.5m/s | 1.5m/s | 1.5m/s |
| Cut-in wind speed (m/s) | 3.5m/s | 3.5m/s | 3.5m/s | 3.5m/s | 3.5m/s |
| Rated speed | 350rpm | 350rpm | 260rpm | 260rpm | 260rpm |
| Rated Wind speed (m/s) | 11m/s | 11m/s | 11m/s | 11m/s | 11m/s |
| Rated voltage(AC) | 12V/24V | 12V/24V | 24V/48V | 48v/96V | 48v/96V |
| Rated power(W) | 30w | 600w | 1000w | 3000w | 5000w |
| Max power(W) | 50w | 610w | 1200 | 3200w | 5200w |
| Rotor Diameter of Blades(m) | 1.2m | 1.7m | 2.5m | 3.3m | 3.5m |
| Blade height(m) | 1.0m | 1.48m | 2.3m | 3.2m | 3.38m |
| Gross weight(kg) | <26kg | <55kg | <180kg | <520kg | <610kg |
| Safe wind speed (m/s) | ≤45m/s | ||||
| Blades quantity | 3 | ||||
| Blade material | Aliminum Alloy | ||||
| Generator | Three phase permanent magnet suspension motor | ||||
| Control System | Electromagnet | ||||
| Mount Height(m) | 2~12m (9m) | ||||
| Generator protection grade | IP54 | ||||
| Work environment temperature | -25~+45ºC, | ||||
