Features
1, Security. Using vertical blades and triangular double-fulcrum, the problems of blade lose/broken or leaf flying-out have been well solved.
2, No noise. Coreless generator and horizontal rotation with aircraft wing design reduce the noise to an unperceivable level in natural environment.
3, Wind resistance. Horizontal rotation and triangular double fulcrum design make it only bear a small wind pressure even in strong wind.
4, Rotation radius. smaller rotation radius than other types of wind turbines, space is saved while efficiency improved.
5, Power generation curve. The power generation increasing gently , it could produce 10% to 30% more power than other types of wind turbines.
6, Brake device. The blade itself has speed protection, and can configure manual mechanical and electronic brake meantime
Specifications
| Model | FH-4000 | FH-5000 | FH-10kw | FH-20kw | FH-30kw |
| Rated power | 4000w | 5000w | 10kw | 20kw | 30kw |
| Maximum power | 4500w | 5500w | 12kw | 22kw | 32kw |
| Rated voltage | 48v-380v | 48v-380v | 220v-380v | 300v-600v | 300v-600v |
| Start-up wind speed | 3m/s | 3m/s | 3m/s | 3m/s | 3m/s |
| Rated wind speed | 10m/s | 10m/s | 10m/s | 10m/s | 10m/s |
| Rated RPM | 300 | 350 | 200 | 160 | 130 |
| Net weight | 220kg | 250kg | 320kg | 680kg | 1280kg |
| Wheel diameter | 2m | 3m | 5m | 5m | 8m |
| Blades height | 2.8 | 3.6m | 6m | 7m | 10m |
| Number of blades | 4 | 3 | 3 | 3 | 5 |
| Blades material | Aluminium alloy | ||||
| Survival wind speed | 45m/s | ||||
| Generator type | 3 phase permanent magnet AC synchronous generator | ||||
| yaw mode | Electromagnet | ||||
| Working temperature | -40°C-80°C | ||||
Why Choose US
1. Competitive Price
--We are the factory/manufacturer so we can control production costs and then sell at the lowest price.
2. Controllable quality
--All products will be produced in our factory so we can show you every detail of the production and let you check the quality of the order.
3. Multiple payment methods
-- We accept online UPI and bank transfer
4. Various forms of cooperation
--We are not only offer you our products, if it is needed, we could be your partner and design product according to your requirement. Our factory is your factory!
5. Perfect after-sales service
--As a manufacturer of wind turbine and generator products for over 4 years,we are very experiences to dealing all kinds of problems. So whatever happens,we will solve it at the first time.
