Specification
| Model | 2000PS-121 | 2000PS-241 | 2000PS-481 |
| Rated power | 2000W | ||
| Peak power | 4000W | ||
| DC input voltage | 12V | 24V | 48V |
| AC output voltage | 110VAC | ||
| No-load current | <0.8A | <0.4A | <0.2A |
| AC output frequency | 60HZ±0.5Hz | ||
| AC output waveform | Pure Sine Wave | ||
| Waveform distortion | THD<3%(Linear load) | ||
| Efficiency | >85% | >88% | >90% |
| DC input voltage range | 10-15V | 20-30V | 40-60V |
| Low Voltage Alarm | 10.5+/-0.5V | 21+/-1V | 42+/-2V |
| Low Voltage Shutdown | 10+/-0.5V | 20+/-1V | 40+/-2V |
| Over Voltage Protection | 15.5+/-0.5V | 31+/-1V | 62+/-2V |
| Low Voltage Recovery | 12+/-0.5V | 24+/-1V | 48+/-2V |
| Over Voltage Recovery | 14.8+/-0.5V | 29.5+/-1V | 59+/-2V |
| Protective Function | Low/Over voltage | LED Red light, automatic recovery | |
| Â | Over load | ||
| Â | Over temperature | ||
| Â | Short circuit | ||
| Â | Input reverse connection | Fuse Burn-out | |
| Fuse Burn-out | 0-40â | ||
| Storage Temp Humidity | (-30)-70â | ||
| Dimension | 300*146*73mmïŒL*W*HïŒ | ||
| Net Weight | 2.6kg | ||
| QTY /Ctn | 12pcs | ||
| Meas./Ctn | 455*355*320mm | ||
| Warranty | 12 Months | ||
Â
| Model | 2000PS-122 | 2000PS-242 | 2000PS-482 |
| Rated power | 2000W | ||
| Peak power | 4000W | ||
| DC input voltage | 12V | 24V | 48V |
| AC output voltage | 220VAC | ||
| No-load current | <0.8A | <0.4A | <0.2A |
| AC output frequency | 50HZ±0.5Hz | ||
| AC output waveform | Pure Sine Wave | ||
| Waveform distortion | THD<3%(Linear load) | ||
| Efficiency | >85% | >88% | >90% |
| DC input voltage range | 10-15V | 20-30V | 40-60V |
| Low Voltage Alarm | 10.5+/-0.5V | 21+/-1V | 42+/-2V |
| Low Voltage Shutdown | 10+/-0.5V | 20+/-1V | 40+/-2V |
| Over Voltage Protection | 15.5+/-0.5V | 31+/-1V | 62+/-2V |
| Low Voltage Recovery | 12+/-0.5V | 24+/-1V | 48+/-2V |
| Over Voltage Recovery | 14.8+/-0.5V | 29.5+/-1V | 59+/-2V |
| Protective Function | Low/Over voltage | LED Red light, automatic recovery | |
| Â | Over load | ||
| Â | Over temperature | ||
| Â | Short circuit | ||
| Â | Input reverse connection | Fuse Burn-out | |
| Fuse Burn-out | 0-40â | ||
| Storage Temp Humidity | (-30)-70â | ||
| Dimension | 300*146*73mmïŒL*W*HïŒ | ||
| Net Weight | 2.6kg | ||
| QTY /Ctn | 12pcs | ||
| Meas./Ctn | 455*355*320mm | ||
| Warranty | 12 Months | ||
