Features
1, Security. Using vertical blades and triangular double-fulcrum, the problems of blade lose/broken or leaf flying-out have been well solved.
2, No noise. Coreless generator and horizontal rotation with aircraft wing design reduce the noise to an unperceivable level in natural environment.
3, Wind resistance. Horizontal rotation and triangular double fulcrum design make it only bear a small wind pressure even in strong wind.
4, Rotation radius. smaller rotation radius than other types of wind turbines, space is saved while efficiency improved.
5, Power generation curve. The power generation increasing gently , it could produce 10% to 30% more power than other types of wind turbines.
6, Brake device. The blade itself has speed protection, and can configure manual mechanical and electronic brake meantime
The parts list
Description | Quantity | REF | |
1 | Blade | 3Â or 4pcs optional | |
2 | Central shaft | 1pc | Centre shaft  TOP×1 |
3 | Brackets | 6Â or 8pcs optional | 3Â pcs blades match 6pcs supports |
4 | Generator | 1Â set | |
5 | Setscrew | M10*856pcs | Fasten the blade and Brackets |
6 | 36pcs | washers | |
7 | 6pcs | Fasten the support and Generator |
Specifications
| Model | FH-4000 | FH-5000 | FH-10kw | FH-20kw | FH-30kw |
| Rated power | 4000w | 5000w | 10kw | 20kw | 30kw |
| Maximum power | 4500w | 5500w | 12kw | 22kw | 32kw |
| Rated voltage | 48v-380v | 48v-380v | 220v-380v | 300v-600v | 300v-600v |
| Start-up wind speed | 3m/s | 3m/s | 3m/s | 3m/s | 3m/s |
| Rated wind speed | 10m/s | 10m/s | 10m/s | 10m/s | 10m/s |
| Rated RPM | 300 | 350 | 200 | 160 | 130 |
| Net weight | 160kg | 220kg | 320kg | 680kg | 1280kg |
| Wheel diameter | 2m | 3m | 5m | 5m | 8m |
| Blades height | 2.8 | 3.6m | 6m | 7m | 10m |
| Number of blades | 4 | 3 | 3 | 3 | 5 |
| Blades material | Aluminium alloy | ||||
| Survival wind speed | 45m/s | ||||
| Generator type | 3 phase permanent magnet AC synchronous generator | ||||
| yaw mode | Electromagnet | ||||
| Working temperature | -40°C-80°C | ||||
